PRODUKTANWENDUNGEN

Elektronikanwendungen

Elektronische Komponenten

Da elektrische Komponenten immer komplexer werden, wächst die Notwendigkeit an spezifischen Messungen, bei denen Qualitätskontrollprozesse vielschichtig und aufwendig werden.

Our probes are used to gauge delicate materials. Applications include checking for flatness or curvature of the surface. The Feather and Ultra Feather Touch has a such a light tip force to prevent surface damage.

Component case gauging

Solartron probes can be used to check the geometry of a cell phone casing or other formed part before assembly. Our 6mm diameter probes can also be used in tighter spaces, which is more important than ever as electronics become more compact.

Check Height of Semi Conductor Wafers

Solartron probes can be used to check the height of SMC Wafers, or even the thickness of various layers.

Hard disk with Flexures

Solartron probes and sensors are used to check critical dimensions of Hard Disk Drive components.

Hard disk with DW10P

Ultra Feather Touch probes are being used to check three points on a small, delicate Hard Disk Drive surface

Non-contact mobile phone

Ensuring measuring systems will not damage the product is of a high importance. Using one of Solartron's Confocal systems, there is no marring to the surface of target material, which can be an issue in the manufacture and testing of electronics.

Solartron Metrology gauging probes and sensors are used today in a wide range of applications throughout the electronics industry. As electrical components become smaller and more intricate, the need to ensure specific measurements are adhered to, grows in importance, with quality control processes becoming fundamental and complex.
